MVH2.0 Medium Voltage Drive: Enclosures



Air cooled compact cabinet

Double-side service zone

Designed to combine the smallest footprint layout with the full performance of a standard drive without any compromises on power or quality. An ideal solution for retrofit projects or any installation with space constraints.



Compact Cabinet Thumb


Air cooled standard cabinet

Double-side service zone

Classic Line up version with design optimization for an overall reduced switch gear width. Power cell cabinet with cell installations from the front and the backside of the cabinet. This switchgear version is a perfect fit for applications with multiple drive installations.



Standard Cabinet 1 Thumb


Air cooled standard cabinet

Front-side service zone

Distribution switchgear style with a single side service access design. This type of VFD is ideal for a wall mounted or back to back installation. It is often used in single installation sites or smaller rooms with a certain limitation of switchgear depth.



Standard Cabinet 2 Thumb


Water cooled cabinet

Front-side service zone

Water cooling provides uniform heat distribution that guarantees lower component temperatures and longer service life. The fully enclosed air-water heat exchange type enclosure provides insulation from outside temperatures and dust.



Water Cooled Cabinet Thumb

MVH2.0 Enclosures

Air cooled compact cabinet

Double-side service zone

Compact Cabinet Thumb

Designed to combine the smallest footprint layout with the full performance of a standard drive without any compromises on power or quality. An ideal solution for retrofit projects or any installation with space constraints.



Air cooled standard cabinet

Double-side service zone

Standard Cabinet 1 Thumb

Classic Line up version with design optimization for an overall reduced switch gear width. Power cell cabinet with cell installations from the front and the backside of the cabinet. This switchgear version is a perfect fit for applications with multiple drive installations.



Air cooled standard cabinet

Front-side service zone

Standard Cabinet 2 Thumb

Distribution switchgear style with a single side service access design. This type of VFD is ideal for a wall mounted or back to back installation. It is often used in single installation sites or smaller rooms with a certain limitation of switchgear depth.



Water cooled cabinet

Front-side service zone

Water Cooled Cabinet Thumb

Water cooling provides uniform heat distribution that guarantees lower component temperatures and longer service life. The fully enclosed air-water heat exchange type enclosure provides insulation from outside temperatures and dust.
